尺寸Dimensions:

18 cm H x 10.7cm L x 7 cm W

重量Weight:

130g

电压Voltage :

5VDC

电流Current :

80mA (standby);  300mA (Operating)

扫描特性/Performance Characteristics

传感器像素Image (Pixels):

VGA 640x480 pixels

光源Light Source:

Aiming& illumination: 617nm LED

视场角Field of View:

45° H

旋转倾斜偏转Roll / Pitch   / Yaw:

30°, ±65°, ±60°

打印对比度Print Contrast:

25% minimum reflective difference

解码能力/Symbology Decode Capability

一维条码/1-D:

UPC-A,   UPC-E, EAN8, EAN13, ISSN,   Telepen, China Post, Trioptic Code, Code128, GS1-128, ISBT 128, Code 39, Code 39 Full   ASCII, Code 32, Code   93, Code11, Matrix 2 of 5, Interleaved 2 of 5,  Codabar, MSI(Plessey), Chinese 2 of 5, GS1 DataBar, Industrial   2 of 5, Standard 2 of 5

二维条码/2-D:

QR, DataMatrix, PDF417, Aztec,   Hanxin etc.

接口支持Interfaces   Supported:

USB, RS232

用户环境/User Environment

工作温度Operating Temperature:

-20°C to   50° C

存储温度Storage Temperature:

 -40° to  80° C

湿度Humidity:

5% to 95%, non-condensing

抗振性Shock Specifications:

Withstands 10Gs 0.06" double amp

抗摔性 Drop Specification

Withstands 50 times 1.6m to concrete

环境光免疫Ambient Light Immunity:

up to 100,000 Lux.

读码景深/Decode Ranges

Symbol & Density

                                        HD Focus

Code 39 (5 mil)

                                   40mm-100mm

100%UPCA (13 mil)

                                   50mm-200mm

Resolution 1D Code 39

                                   4mil (0.075mm)

Performance may be impacted by bar code   quality and environmental conditions
